Furthermore, thanks to its low ground pressure and exceptional stability, the Hammar 110 side loader trailer is frequently utilized for military logistics deployment, the transport of mining equipment, and the rapid delivery of emergency relief supplies.
The Hammar 110 side loader trailer represents a cutting-edge model in its field, renowned for its lightweight construction and dual-mode outrigger design. The Hammar side loader is one of the lightest models in its class (the 3-axle version has a tare weight starting at approximately 8.4 tons).
The Hammar sideloader allows for the legal transport of heavier cargo, thereby enhancing the profitability of each individual transport run.
Hammar 110 Side Loader Trailer for Sale In Guyana
Hammar 110 Side Loader Trailer for Sale In Guyana
Hammar 110 Side Loader Trailer for Sale In Guyana
Max. lifting capacity: 37Ton
Dimension(L*W*H): 14100*2500*4200mm
Axle: 3 axle, 13 ton (220mm brake pads)
Tire: 12 pcs, 12R22.5
Suspension: Heavy-duty type mechanical spring suspension
Kingpin: 3.5-inch bolted type
Landing gear: JOST
Power source: Power take-off (equipped)
The Hammar 110 side loader trailer features outriggers with two distinct operating modes, allowing it to adapt to various operational environments. In one mode, the Hammar side loader extends its outriggers to span over another trailer or railway tracks. This mode offers maximum stability and exerts minimal ground pressure, making it ideal for operations on soft ground or for vehicle-to-vehicle transfers.
In the other mode, the Hammar sideloader's outriggers remain folded, resting directly on the ground adjacent to the vehicle's side. This mode facilitates faster operations and excels in confined spaces, such as narrow warehouse entryways.
The Hammar 110 side loader trailer features a standard lifting capacity of 36 tons, with an optional upgrade available to 40 tons. The Hammar side loader can complete a full loading and unloading cycle in just 2 to 4 minutes. The Hammar sideloader also offers an optional two-tier stacking capability, allowing for the stacking of High Cube containers.
The Hammar 110 side loader trailer allows its cranes to extend up to 6 meters. It can even reach over a row of containers to lift cargo from a second row (lifting up to 15–17 tons), significantly enhancing operational flexibility within container yards.
The Hammar 110 side loader trailer is equipped with a high-precision remote control system, enabling the operator to stand within a safe line of sight and precisely control the lifting process.
The Hammar side loader is ideally suited for the direct transfer of containers between railway flatcars, other trailers, or trucks, eliminating the need to rely on expensive terminal cranes or reach stackers.
The Hammar sideloader can independently perform ground-to-ground container transfers—lifting a container from the ground and placing it back down—thereby enabling true "door-to-door" service. Due to its lightweight construction and rapid transfer speeds, it is particularly well-suited for logistics companies requiring frequent short-haul distribution and multiple transshipments.
