This is done with a 20 ft side lifter truck which is a side loader truck fitted with cranes at both ends. 20 ft side lifter truck enables easier and efficient handling of 20-40 foot containers.
With a 37ton lifting capacity, the 20 ft side lift truck is quick and stable and boasts an outreach of more than four meters to provide ease of operation.
Side Lifter Truck for Sale | 20 ft Side Lift Truck
Side Lifter Truck for Sale | 20 ft Side Lift Truck
Side Lifter Truck for Sale | 20 ft Side Lift Truck
Max. lifting capacity: 37Ton
Max.stabilizer outreach: 3200mm
Max.working range: 4000mm
Overall height: 2500mm
Overall length: 1020mm
Landing gear: JOST
Tow Chain: lgus (imported)
Power source: Power take-off (equipped)
Hydraulic pump: Gear type Casappa Italy
Direction control valves: AMCA Holand
Remote Control: NBB Germany
Max. pressure of hydraulic system: 28Mpa
Dimension(L*W*H): 12000x2500x4000mm
Axle: 2axle* 13 ton (220mm brake pads)
Tire: 8pcs, 12R22.5
Suspension: Heavy duty type mechanical spring suspension
Kingpin: 3.5 inch bolted type
Braking system: WABCO Emergency valve
TITAN 20 ft side lifter truck is made of Q345 high strength steel with a main beam height of 500mm and a thickness of 10mm.
The upper plate and the bottom plate are 20mm thick and 140mm wide, making the side lift plate stronger.
Our 20 ft side lift truck is equipped with 12 container locks.
TITAN is currently the largest supplier of side lift trucks, we have exported hundreds of 20 ft side lift trucks to the world. They have all been well received by customers.
Through this video below, you can learn about different types of container side loader trailers, as well as the process, testing, packaging and customer feedback, etc.
